Key Facts

What is Revit
Autodesk Revit is a building information modeling (BIM) software used by architects, landscape architects, structural engineers, NEP engineers, designers, and contractors.
Pricing
Monthly Subscription: $305 / Annual Subscription: $2,425
Free Trial
Yes, 7-30 days
Customer Service
Yes, business hours
Platforms
Windows
Compatibility
Autocad Rhino Archicad 3DMax Vectorwork Sketch-up
Features
-
