This Case Study showcases all 4 of our disciplines, Architecture, Structure, MEPF and Landscape in a single model at our LoD 350 standard. The model contains 3 buildings, 11 storefronts and two rail systems below. Coordinating with the MTA / LIRR was a huge learning experience for us as we continue to work in transportation projects.

Project Overview:
-Project Type: Commercial with Transportation
-Size: Over 32,000 sqft
-Scan Duration: Completed in 3 days with a 2-man team
-Complex Structural MEPF Scanning: Including active public areas and active rail.

Model Contents:
-Includes office, restaurant, retail, industrial, structural, MEPF, and transportation components

Queens City Block with Rails

Why Scan2Plan?

-Experienced team of in-house team of experienced field techs, drafters (AutoCAD and Revit) and licensed engineers
-We take the time to scope each project to suit your priorities
-We use the finest precision tools to capture a point cloud with extreme accuracy
-Drafted to Scan2Plan’s rigorous design standards - your design phase begins upon delivery
-We take a process-driven approach with extensive quality control and team review
-Exceptional support from real professionals
-Scan2Plan has national reach through our authorized service partners
-We work on a wide range of projects from residential to large-scale commercial and industrial

Schedule a discovery call today!
