Problem:
For structural concrete, any error outside of construction tolerances requires an engineering redesign and often involves costly and timely remedial works:

Breaking, cutting, drilling concrete
Reordering structural reinforcement and concrete
Recasting the concrete and allowing for curing times

Scope of Works:
The Main Contractor partnered with XYZ Reality prior to breaking ground, for the construction of their concrete foundations to ensure that they are built correctly (+/- 5mm) and ready for the structural steel columns:

Incorporating The Atom into the project’s Inspection, Testing and Planning process
Inspecting the structures at the lowest value stage - during the setting-out and during the installation of the reinforcement, embedded elements (including holding-down bolts) and formwork

Results:
In all areas where The Atom was deployed, any errors or issues were detected prior to the concrete pour and the concrete foundations were installed within tolerances and without defects.

For the one location where The Atom could not be deployed, the concrete foundation was built 500mm out of tolerance.

However, using The Atom’s real-time validation, this issue was raised immediately and prior to any ground infill and the steel column installation

XYZ Reality Client Success Story

The Atom is a powerful, custom-built engineering tool combining a construction safety headset, augmented reality displays and in-built computing power. 

With The Atom, construction teams can view 3D models to millimetre accuracy onsite.

With The Atom, construction teams can view 3D models to millimetre accuracy onsite.

XYZ Reality

The Atom is a powerful, custom-built engineering tool combining a construction safety headset, augmented reality displays and in-built computing power. 
